5 sizes with wide chances of several mounting positions.
Available only in motor connection (PAM) execution
High Performance Rates
Max. applicable power 12.5 kW.
Max. trasmissibile torque 800 Nm (*).
Ratios up to 100/1.
(*) Total output torque that can be apportioned on two axes with the maximum ratio 40% – 60%.
High Reliability
Housing built in pressure die casting aluminium, designed in order to guarantee lightness, strength and stiffness.
“ZI” teeth profile on worm and wormwheels for a silent working without vibrations.
5 sizes with wide chances of several mounting positions.
Available only in motor connection (PAM) execution
High Performance Rates
Max. applicable power 12.5 kW.
Max. trasmissibile torque 800 Nm (*).
Ratios up to 100/1.
(*) Total output torque that can be apportioned on two axes with the maximum ratio 40% – 60%.
High Reliability
Housing built in pressure die casting aluminium, designed in order to guarantee lightness, strength and stiffness.
“ZI” teeth profile on worm and wormwheels for a silent working without vibrations.
Additional Info
Additional Info
| Brand | Siti |
|---|
